3-6
Expansion Master Unit and Expan-
sion Slave Unit
This section describes the Expansion Master Unit and the Expansion Slave Unit.
3-6-1
Models and Specifications
Models and Outline of Specifications
The models and outline of specifications are given below.
Unit type Model
Expansion Master Unit CK3W-EXM01
Expansion Slave Unit CK3W-EXS02
Specifications
Expansion cable For connection between the Expansion Master Unit and the Expansion Slave
Unit, be sure to use the following cable.
CK3W-CAX003A (0.3 m)
Power consumption CK3W-EXM01: 5 V 0.4 W max.
CK3W
-EXS02: 5 V 0.2 W max.
Dimensions (height ×
depth × width)
90(H)/80(D)/31.6(W)
Weight CK3W-EXM01: 100 g max.
CK3W
-EXS02: 130 g max. (including End Cover)
3 Configuration Units
3-59
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
3-6 Expansion Master Unit and Expansion Slave Unit
3
3-6-1 Models and Specifications
