General Specifications
This section describes the Motion Controller specifications.
Item Specification
Enclosure Mounted in a panel
Grounding Method Ground to less than 100 Ω.
Operating Environ-
ment
Ambient Operating
T
emperature
0 to 55°C
Ambient Operating Hu-
midity
10% to 95% (with no condensation or icing)
Atmosphere Must be free of corrosive gases.
Ambient Storage Tem-
perature
-25 to 70°C (with no condensation or icing)
Vibration Resistance
Conforms to IEC 60068-2-6.
5 to 8.4 Hz with 3.5-mm amplitude,
8.4 to 150 Hz, acceleration of 9.8 m/s
2
100 min each in X, Y
, and Z directions (10 sweeps of 10
min each = 100 min total)
Shock Resistance
Conforms to IEC 60068-2-27.
147 m/s
2
, 3 times each in X, Y
, and Z directions
Insulation Resistance 20 MΩ min. between isolated circuits (at 100 VDC)
Dielectric Strength
510 VAC between isolated circuits for 1 minute with a
leakage current of 5 mA max.
Applicable Standards cULus, EU: EN 61326, RCM, KC, EAC
