Omron CK3M Series - Part Names and Functions

3-1-2
Part Names and Functions
(A)
(B)
(J)
(I)
(H)
(G)
(C)
(D)
(E)
(F)
(K)
(L)
Letter Name Function
A Slider Holds the Units together.
B CPU Unit operation indicators Shows the operation status of the CPU Unit using multiple in-
dicators.
C EtherCAT communications connector Connects to an EtherCAT network communications cable.
3 Configuration Units
3-5
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
3-1 CPU Unit
3
3-1-2 Part Names and Functions
