Connection diagram
*2
FG
EQ
Un
COM_EQU
*1. Since the OFF current is small, connection to the two-wire sensor may not be successful. Refer to Precau-
tions When Connecting a T
wo-wire DC Sensor on page 5-29 for information on using the two-wire sensor.
*2. For high-speed output, we recommend the use of shielded wiring.
3-3-14
General Digital I/O Connection Terminal Block Specifications
This section describes the terminal arrangement and electrical specifications of the general digital I/O
connection terminal block.
Terminal Arrangement

NPN Type
1
18
19
38
3 Configuration Units
3-36
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
