Omron CK3M Series - Page 105

(A)
(C)
(B)
Letter Name Model
A Expansion Master Unit CK3W-EXM01
B Expansion cable CK3W-CAX003A
C Expansion Slave Unit CK3W-EXS02
3 Configuration Units
3-61
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
3-6 Expansion Master Unit and Expansion Slave Unit
3
3-6-4 System Configuration
