Omron NX Series - Removing NX Units

1 Unlock the DIN Track mounting hook.
Use a flat-blade screwdriver to pull up the DIN Track mounting hook to unlocked position.
At this point, be sure not to drop the CPU Unit
.
2 Remove the CPU Unit from the DIN Track.
Tilt the Unit diagonally upwards and pull it up slightly
, then pull it out to remove. Be careful not
to drop it.
(1)
(2)
(3)
5-3-12
Removing NX Units
Precautions for Safe Use
Always turn OFF the Unit power supply and I/O power supply before you remove the NX Unit.
1 Use a flat-blade screwdriver to pull up the DIN Track mounting hook on the Unit to remove.
5 Installation and Wiring
5-30
NX-series NX502 CPU Unit Hardware User's Manual (W629)
