Omron NX Series - Connecting to the Sysmac Studio

2-2
Connecting to the Sysmac Studio
Connect the NX-series NX502 CPU Unit and the Sysmac Studio through EtherNet/IP.
Refer to 3-6-2 Connection on page 3-18 for information on how to make the connection between the
NX-series NX502 CPU Unit and the Sysmac Studio.
2 System Configuration
2-8
NX-series NX502 CPU Unit Hardware User's Manual (W629)
