Omron NX Series - Page 95

(A)
(B)
(C)
(D)
LOT No. DDMYY£
V
er.£.££
££££££££££££
HW Rev.£
PORT1:
££££££££££££
PORT2:
££££££££££££
PORT3:
SSSS
Let-
ter
Name Function
A Unit version Shows the unit version of the CPU Unit.
B Lot number and serial
number
Shows the lot number and the serial number of the CPU Unit.
DDMYY: Lot number
, £: For use by OMRON, SSSS: Serial number
M is 1 to 9 for January to September, X for October, Y for November, and Z
for December.
C Hardware revision Shows the hardware revision of the CPU Unit.
D MAC addresses Shows the MAC addresses of PORT1, PORT2, and PORT3 on this Unit.
