Using Ferrules
If you use ferrules, attach the twisted wires to them.
Observe the application instructions for your ferrules for the wire stripping length when attaching
ferrules.
Always use plated one-pin ferrules. Do not use unplated ferrules or two-pin ferrules.
The applicable ferrules, wires, and crimping tools are listed in the following table.
Terminal
types
Manufactur-
er
Ferrule model
*1
Applicable wire
(mm
2
(AWG))
Crimping tool (applicable wire size given in pa-
rentheses)
All terminals
except
ground ter-
minals
Phoenix
Contact
AI0,25-8
0.25 (#24) Phoenix Contact
CRIMPFOX 6 (0.25 to 6 mm
2
, A
WG24 to 10)
AI0,5-8
0.5 (#20)
AI0,5-10
AI0,75-8 0.75 (#18)
AI0,75-10
AI1,0-8 1.0 (#18)
AI1,0-10
AI1,5-8 1.5 (#16)
AI1,5-10
Ground ter-
minals
AI2,5-8 2.5 (#14)
AI2,5-10
All terminals
except
ground ter-
minals
Weidmuller H0.14/12 0.14 (#26) Weidmuller
PZ 6 Roto (0.14 to 6 mm
2
, A
WG26 to 10)
H0.25/12 0.25 (#24)
H0.34/12 0.34 (#22)
H0.5/14 0.5 (#20)
H0.5/16
H0.75/14 0.75 (#18)
H0.75/16
H1.0/14 1.0 (#18)
H1.0/16
H1.5/14 1.5 (#16)
H1.5/16
Ground ter-
minals
H2.5/15D 2.5 (#14)
H2.5/16DS
All terminals
except
ground ter-
minals
Wago FE-0.25-8N 0.25 (#24) Wago
V
ariocrimp 4 (0.25 to 4 mm
2
, A
WG24 to 12)
FE-0.34-8N 0.34 (#22)
FE-0.5-8N 0.5 (#20)
FE-0.5-10N
FE-0.75-8N 0.75 (#18)
FE-0.75-10N
FE-1.0-8N 1.0 (#18)
FE-1.0-10N
FE-1.5-8N 1.5 (#16)
FE-1.5-10N
Ground ter-
minals
FE-2.5-8N 2.5 (#14)
FE-2.5-10N
*1. This represents a typical model. Actually, colored codes and other information is added.
When you use any ferrules other than those in the above table, crimp them to the twisted wires so
that the following processed dimensions are achieved.
5 Installation and Wiring
5-53
NX-series NX1P2 CPU Unit Hardware User’s Manual (W578)
5-4 Wiring
5
5-4-8 Wiring to the CPU Unit Terminal Block
