Omron SMARTSTEP 2 SERIES User Manual

3-67
3-5 Servo Relay Units and Cable Specifications
3
Specifications
 Position Control Unit Cable (XW2Z-@J-A6)
This Cable connects a Position Control Unit (CS1W-NC113, C200HW-NC113) to a Servo Relay
Unit (XW2B-20J6-1B).
Cable Models
Connection Configuration and External Dimensions
Wiring
Model Length (L) Outer diameter of sheath Weight
XW2Z-050J-A6 50 cm
8.0 dia.
Approx. 0.1 kg
XW2Z-100J-A6 1 m Approx. 0.1 kg
38
L647
83
t = 11
Position Control Unit
CS1W-NC113
C200HW-NC113
Servo Relay Unit
XW2B-20J6-1B
No.
Position Control Unit
A1
A2
A8
A6
A10
A16
A14
A24
A12
A21
A23
A22
A19
A20
Servo Relay Unit
Cable: AWG28 × 4P + AWG28 × 10C
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Crimp terminal
