STC-MBS122BPOE / STC-MCS122BPOE
Product Specifications and User’s Guide
5 Specifications
5.1 Electronic Specifications
Product
STC-MBS122BPOE
STC-MCS122BPOE
Image Sensor
1.1” 12M Progressive Monochrome CMOS
(SONY: IMX304)
1.1” 12M Progressive Color CMOS
(SONY: IMX304)
Shutter Type
Global Shutter
Active Picture Elements
4,096 (H) x 3,000 (V)
Cell Size
3.45 (H) x 3.45 (V) µm
Scanning Mode
Full scanning (Full resolution) / ROI
Frame rate (at full scanning)
8bits: 8.9 fps / 10bits: 4.4 fps / 10bits Packed: 5.9 fps /
12bits: 4.4 fps / 12bits Packed: 5.9 fps / RGB8: 2.9 fps
Maximum frame rate: : 829.9 fps @ 4 lines (8bits)
ADC bit depth
12bits
Image Output Format
Mono8 / Mono10 / Mono10Packed /
Mono12 / Mono12Packed
Mono8 / Mono10 / Mono10Packed /
Mono12 / Mono12Packed /
BayerRG8 / BayerRG10 / BayerRG10Packed /
BayerRG12 / BayerRG12Packed / RGB8
Noise
Level
8bits output
Less than 3.0 digits (Gain 0 dB)
10bits / 10bits Packed output
Less than 12.0 digits (Gain 0 dB)
12bits / 12bits Packed output
Less than 48.0 digits (Gain 0 dB)
Sensitivity (*1)
430 Lux
850 Lux
Exposure Time
1 µseconds to 16.777 seconds (Default: 111,291 µseconds)
Gain
Analog Gain
0 to 20.8 dB (Default: 0 dB)
Digital Gain
x1 to x3 (Default: x1)
ROI
Horizontal: 264 to 4,096 pixels, Vertical: 4 to 3,000 lines (Default: 4,096 x 3,000)
Adjustable steps for size: 8 pixels in horizontal direction and 4 lines in vertical direction
Adjustable steps for offset: 8 pixels in horizontal direction and 4 lines in vertical direction
Gamma
Gamma 0.1 to 4.0 (Default: 1.0)
Binning
N/A
Decimation
Horizontal and Vertical decimation (2x2) / Off
Image Flip
Horizontal / Vertical / Horizontal and Vertical / Off
Defective Pixel Correction
Up to 2,048 points (Default: On)
Auto
Control
Auto Exposure
Support (Default: Off)
Auto Gain
Support (Default: Off)
Auto White Balance
N/A
Auto / Manual / Push to Set
Operational Mode
Edge preset trigger / Pulse width trigger / Free run
Interface
PoE: IEEE802.3af CLASS2 (1000BASE-T)
Protocol
GigE Vision 2.1 and GenICam SFNC 2.4, IEEE1588 (PTP)
I/O
One opto-isolated input, one opto-isolated output and one open collector GPIO (Input or output)
Power
Input Voltage (*2)
+10.8 to +26.4 Vdc External power (via 6 pin connector) /
Power Over Ethernet (IEEE802.3af)
Consumption
+12 V / +24 V: 4.1 W, PoE: 4.4 W
Default: Bold
