STC-MBS122BPOE / STC-MCS122BPOE
Product Specifications and User’s Guide
Auto shutter
The brightness of image maintains to keep target brightness with shutter automatically.
If the brightness of image is darker than target brightness, exposure time extends up to
“ExposureAutoLimitMax”.
If the brightness of image is brighter than target brightness, exposure time becomes shorter up to
“ExposureAutoLimit Min”.
GenICam Parameters
Auto shutter ON / OFF selection
Selection: “ON” (Continuous), “OFF” (Off)
Default: “OFF”
Minimum exposure time (in µsecond) for auto shutter
Range: 1 to 16,777,215
Default: 17
Maximum exposure time (in µsecond) for auto shutter
Range: 1 to 16,777,215
Default: 111,291
ALC settings procedure
ALC Settings Procedure
1. Sets “AutoLuminanceWidth”, “AutoLuminanceHeight”, “AutoLuminanceOffsetX”,
“AutoLuminanceOffset Y” and “AutoLuminanceWeight” for “AutoLuminanceRegion 0 to 8”.
2. Sets “Continuous” for “GainAuto” when using AGC function.
3. Sets “GainAutoLimitMin” and “GainAutoLimitMax” when using AGC function.
4. Sets “Continuous” for “ExposureAuto” when using auto shutter function.
5. Sets “ExposureAutoLimit Min” and “ExposureAutoLimitMax” when using auto shutter function.
6. Sets “AutoLuminanceTarget”.
