STC-MBS122BPOE / STC-MCS122BPOE
Product Specifications and User’s Guide
10.17 Counter And Timer Control
Controls “Timer” and “Counter”.
A) Timer Control
GenICam Parameters
Delay for “Timer 0 active” signal (in µsecond)
Range: 0 to 16,777,215
Default: 0
Duration of “Timer 0 active” signal (in µsecond)
Range: 1 to 16,777,215
Default: 1
Reference signal selection to generate “Timer 0 active” signal
Default: “Off”
Polarity of reference signal to generate “Timer 0 active” signal
Default: “RisingEdge”
Returns value for “Timer 0 active” signal
When the timing of “Timer 0 active” signal is adjusting to active signal of Exposure, “Timer 0” can be used as
strobe control signal.
B) Counter Control
GenICam Parameters
Counter selection
Default: “Counter 0”
Counter event source selection
Reference signal selection to reset counter
Polarity of reference signal to reset counter
Rest switch
“Activate as switch when selecting “Software” at “CounterResetSource”
Returns number of counter
