Appendix BSpecifications
174
Pin 3: Minimum Pulse Width Setting of Pulse Input Response
Use pin 3 only when pin 2 of the C200H-ID501, C200H-ID215, C200H-MD501, C200H-MD115, and C200H-
MD215 is set to ON (i.e., when pulse input is set).
Pin 3 Minimum response input pulse width
OFF 1 ms
ON 4 ms
Pin 4: Input Response Time Setting
Use pin 4 for the C200H-ID501, C200H-ID215, C200H-MD501, C200H-MD115, and C200H-MD215 only.
Pin 4 Input response time
OFF 2.5 ms max.
ON 15 ms max.
Pin 5: Dynamic Data Output Logic Setting
Use pin 5 only when the C200H-OD501 or C200H-OD215 is in dynamic output mode (i.e., when pin 1 is set to ON).
Pin 5 Data output
OFF Negative logic output
ON Positive logic output
DIP Switch Settings for High-density I/O Unit (Special I/O Unit)
Model Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6
C200H-ID501/215 Setting is
not required
Must be set Set when
pulse input
is used
Must be set Setting is
not required
Setting is
not required
C200H-OD501/215 OFF Setting is
not required
Setting is
not required
Setting is
not required
Setting is
not required
Setting is
not required
ON Setting is
not required
Setting is
not required
Setting is
not required
Must be set Setting is
not required
C200H-MD501/115/215 OFF Must be set Set when
pulse input
is used
Must be set Setting is
not required
Setting is
not required
ON Setting is
not required
Setting is
not required
Setting is
not required
Setting is
not required
Setting is
not required
