Omron SYSMAC C200HS Installation Guide

13
1-6 Compatibility of C200HS and C200H Devices
Completely compatible: C200H devices can be used with the C200HS as is.
Replacement Units: These Units were developed for the C200HS and can be
used for both the C200H and the C200HS.
C200HS only: These devices can only be used with the C200HS.
Classification Type of Unit Completely
compatible
Replacement
Units
C200HS only Remarks
CPU Rack
CPU Yes C200HS-CPU01-E/01-EC
/03-E/21-E/21-EC/23-E/
31-E/33-E
Backplane Yes C200H-BC031-V2/051-V2
/081-V2/101-V2 (Existing
Backplanes can be used
if Interrupt Input Units are
not used.)
Memory Cassette Yes C200HS-ME16K/MP16K
Expansion I/O
Rack
Yes Configured based on
Backplane and I/O Power
Supply Unit.
I/O Connecting
Cable
Yes One cable is required to
connect one Expansion
I/O Rack.
I/O Unit
8/12/16-pt. I/O
Units
Yes
Standard B7A
Interface Units
Yes 16 pts.
Group-2
High-density I/O
Unit and Group-2
B7A Interface
Units
Yes 32 pts. or 64 pts.
Special I/O Unit Yes High-speed Counters,
Position Control Units,
High-density I/O Units,
Analog I/O Units,
Temperature Sensor
Units, ASCII Units, etc.
Interrupt Unit Yes When mounting an
Interrupt Input Unit, use
the C200H-BCjj1-V2.
Remote I/O
(O i l)
Master Unit Yes C200H-RM001-PV1
(Optical)
Slave Unit Yes C200H-RT001-P/002-P
Remote I/O
(Wi d)
Master Unit Yes C200H-RM201
(Wired)
Slave Unit Yes C200H-RT201/201-C/202
Link
Host Link Unit Yes C200H-LK101-PV1
C200H-LK201-V1
C200H-LK202-V1
PC Link Unit Yes C200H-LK401
SYSMAC LINK Yes C200HW-SLK13/SLK14
C200HW-SLK23/SLK24
SYSMAC NET
Link
Yes C200HS-SNT32
Peripheral
Device
Programming
Console
Yes C200H-PRO27-E
CQM1-PRO01-E
ece
SSS Yes C500-ZL3AT1-E
Compatibility of C200HS and C200H Devices Section 1-6
