Function ModelFunction
C200HC200HS
Interrupt function
Scheduled interrupts
Interrupt period
Interrupt response time
Input interrupts
Interrupt Input Unit
Backplane
Interrupt response time
10 ms x SV or 1 ms x SV
10 ms max. (C200H common mode,
Communications Unit connected)
1 ms (C200HS mode,
Communications Unit not connected)
8 points max.
C200HS-INT01 (8 points)
C200H-BCjj1-V2 (corresponding to
Interrupt Input Unit)
1 ms max. (10 ms max. when
Communications Unit connected)
10 ms x SV
10 ms max.
No interrupt input function
C200H-BCjj1-V1 (Interrupt Input
Unit not possible.)
Debugging and maintenance Forced set/reset
Data trace
Differential monitor
Forced set/reset
Programming Console operations Decimal display of binary data
Continuation of display when modes
are switched
Terminal mode and expansion
terminal mode
Terminal mode
Peripheral Devices
Connection method
Cable for personal computer
SYSMAC Support Software (SSS)
I/O comments
Online editing
Direct connection to C200HS.
CQM1-CIF02
C500-ZL3AT1-E
Can be stored in C200HS
Cycle time over non-detection setting
possible.
Connection via Peripheral Interface
Unit or Host Link Unit.
C500-ZL3AT1-E
Communications Units
SYSMAC NET Link
SYSMAC LINK
For C200HS-CPU31-E/CPU33-E
C200HS-SNT32
C200HW-SLK13/SLK14 (Optical)
C200HW-SLK23/SLK24 (Coaxial)
C200H-SNT31
C200H-SLK11
C200H-SLK21-V1
Built-in Host Link
1-to-1 link
NT link
RS-232C connector built into the
C200HS-CPU21-E/CPU21-EC/
CPU23-E/CPU31-E/CPU33-E
LR Area is shared by connecting
RS-232C connectors.
High-speed communications with
Programmable Terminal (PT) via
RS-232C connector.
---
Host Link Units
Added function
Optical cable
RS-232C
RS-422
Transmission possible by means of
TXD instruction.
C200H-LK101-PV1
C200H-LK201-V1
C200H-LK202-V1
C200H-LK101-P
C200H-LK201
C200H-LK202
Comparisons Between C200HS and C200H Section 1-5
