Revision History
A manual revision code appears as a suffix to the catalog number on the front cover of the manual.
Cat. No. W236-E1-07
Revision code
The following table outlines the changes made to the manual during each revision. Page numbers refer to the
previous version.
Revision code Date Revised content
1 December 1993 Original production
2 August 1994
Page 7: Flowchart changed.
Pages 8, 9, 11, 12 14, 16, 17, 31, 33, 40, 41, 56, 81, 91, 92,
156, 158, 159, 163: New CPU information added.
Pages 9, 11: Interrupt information added.
Page 9: RS-232C information added.
Pages 9, 12, 11 14, 56, 85, 162: New SYSMAC LINK Units
and SYSMAC NET Link Unit information added.
Pages 10 to 12: Information in the tables corrected.
Page 17: DIP switch pin no. 5 function description changed.
Page 43: Backplane Insulation Plate information changed.
Page 88: SYSMAC LINK/SYSMAC NET Link Optical Fiber
Products added.
Pages 151 to 153: Temperature Control Unit, Fuzzy Logic
Unit, and Cam Positioner Unit specifications removed.
3 February 1995
Group-2 B7A Interface Units were added beginning on
page 156 and to the following pages: 13, 85, 95, 154, 158,
159, and 164–165
Page 11: Execution time and number of instructions changed.
Page 13: “Link compatible” and accompany text corrected.
Page 20: Power supply diagrams added for CPUs.
Page 34: Information on Interrupt Input Unit added.
Page 35: Caution added.
Page 36 and 44: Diagram corrected.
Page 39: Corrected first step and table in installation proce-
dure.
Page 67: 5-6 SYSMAC Support Software (SSS) added.
Page 72: 9D correction added.
Page 73: First FAL number changed and “Communications
Errors” added.
Page 75: Table corrected.
Page 78 and 80: Steps added to fuse and relay replacement
procedure and illustrations changed.
Page 90: Link Adapter model deleted.
Page 93: Small correction for LSS. SSS models added.
Page 168: RS-232C port specifications added.
Minor changes were made to the following pages: 16, 17,
23, 24, 58, 81, 83, 93, 95, and 164.
3A October 1995
Page 9: Maximum number of I/O points for Remote I/O Sys-
tem with Slave Units corrected to 800 points from 560 points.
Pages 12, 13: LSS replaced with SSS in the table.
Page 21: Functions for pin 5 in the table corrected. Notes
added.
Page 26: C200H-ID111 added to table.
Page 42: 24-VDC output connections added to the diagram.
Text added to the bottom of page.
Page 43: Bottom diagram changed and text deleted from the
bottom of page.
Page 46: Caution removed.
Page 63: C200H-DA002 added.
Page 81: Note rewritten.
Pages 83, 84: DANGER note moved.
Pages 85 to 93: Standard models updated and corrected.
Page 109: C200H-OA224 added.
Page 127: C200H-ID111 added.
Page 139 to 153: Some resistance figures removed from the
circuit configurations. C200H-OA121-E added. Other minor
corrections.
Pages 160 and 170: Specifications and notes corrected.
Page 173: Current consumptions for C200H-OA121-E,
C200H-OA224, C200H-ID111, and C200H-DA002 added.
4 August 1996
Pages 8, 9, 10, 13, 16, 18, 19, 20, 35, 37, 44, 46, 86, 87, 97,
98, 99, 173, 174, 178: New C200HS-CPU01-EC/CPU21-EC/
CPU23-EC CPU and related information added.
Pages 8, 18, 20, 87: Conformance to EC directives and
related information added for C200HS-CPU03-E CPU.
Pages 3, 12, 13, 61, 91, 95, 177: C200HS-SLK12/SLK22
SYSMAC LINK Units changed to C200HW-
SLK13/SLK14/SLK23/SLK24.
Page 13: C200H-RT201-C added to Remote I/O (Wired)
Slave Units.
Page 21: Pin No. 6 function clarified.
Pages 21, 58, 95, 179: C200HS-CN222 and C200HS-CN422
Connecting Cables added.
Pages 24, 44, 46, 87, 97, 173, 178: New C200H-PS221-C
Power Supply Unit and related information added.
Pages 24, 45: Terminal connections changed for
C200H-PS211.
Pages 24, 87: Conformance to EC directives and related
information added for C200H-PS211 Power Supply Unit.
Pages 25, 26, 97: E-shape Units added.
Pages 36, 88, 128, 176: C200H-OD21A added.
Page 46: Notes added to the top and bottom of the page.
Page 82: Fuse specifications table added.
Pages 88, 101, 175: C200H-IA122V added.
Pages 88, 103. 175: C200H-IA222V added.
Pages 88, 112, 176: C200H-OA222V, C200H-OA223,
C200H-OA122-E added. C200H-OA222 deleted.
Page 111: Fuse voltage corrected for C200H-OA121-E circuit
configuration.
Page 113: Residual voltage for C200H-OA224 corrected.
Minor corrections made to the circuit configuration.
Page 91, 177: CompoBus Units added.
Page 92: 3G2A9-AL006-E deleted from Link Adapters.
Page 163: Minor addition made to the B7A transmission delay
Pages 171, 172: Voltage correction made for the common
power supply in the diagrams.
Pages 179 to 185: Dimensions section rearranged and cor-
rected.
5 April 1997
PLP section added in from of Section 1. Relay Output Units
changed to Contact Output Units throughout the manual.
C200H-CPU23-EC removed throughout the manual.
Page 27: Note on C200H-OC226 dimensions added.
Pages 85 to 87: Output Unit Relay and Output Units added to
the procedure.
Pages 90, 122, 180, 182: C200H-OC222V, C200H-OC224V,
and C200H-OC226 Contact Output Units added.
Page 94: Relay added to Optional Products.
Page 123: New Contact Output Units reflected.
Page 186: C200H-OC226 dimensions added.
6 June 1999
Page 28: C200H-ID218, C200H-ID219, and C200H-OD21B
added.
Page 46: Crimp terminal information added.
Page 53: Precautions for connecting two-wire sensors added.
Pages 92, 114: C200H-OA221 removed from C200H Stan-
dard I/O Units.
Page 93: C200H-ID218, C200H-ID219, and C200H-OD21B
added to C200H Group-2 High-density I/O Units.
Page 101: Vibration, shock, grounding, and enclosure rating
information corrected.
Pages 131, 132: C200H-OD212 and C200H-OD213 circuit
configurations corrected.
Page 138: C200H-OD21A information corrected.
Page 145: C200H-ID218 and C200H-ID219 information
added.
Page 148: C200H-OD21B information added.
Page 186: C200H-ID218, C200H-ID219, and C200H-OD21B
added to Current Drawn from 5-V Supply for Group-2 High-
density I/O Units.
07 March 2003
Page 22: Information in table changed in several places.
Pages 149, 151, 160, 162, 169, 171: Minor changes made to circuit configuration dia-
grams.
Page 180: Information related to connectable B7A Link Terminals changed and added in
several places.
Pages 202, 203: System configuration added and connection diagrams corrected.
