Appendix BSpecifications
180
Connectable B7A Link Terminals
Only 16-point B7A Link Terminals can be connected to a B7A Interface Unit.
Input Terminals
Type Model Transmission delay
Screw terminals
B7A-T6j1
Standard (19.2 ms)
B7AS-T6j1
()
B7A-T6j6
High-speed (3 ms)
B7AS-T6j6
gp ( )
Modular
B7A-T6D2 Standard (19.2 ms)
B7A-T6D7 High-speed (3 ms)
PC connectors
B7A-TjE3
Standard (19.2 ms)
B7A-TjE8
High-speed (3 ms)
Output Terminals
Type Model Transmission delay
Screw terminals
B7A-R6jj1
Standard (19.2 ms)
B7AS-R6jj1
()
B7A-R6jj6
High-speed (3 ms)
B7AS-R6jj6
gp ( )
Modular
B7A-R6A52 Standard (19.2 ms)
B7A-R6A57 High-speed (3 ms)
PC connectors
B7A-RjAj3
Standard (19.2 ms)
B7A-RjAj8
High-speed (3 ms)
Note 1. Do not connect Terminals with different transmission delays to the same Interface Unit. Doing so will
cause a transmission error.
2. The 10-point B7A Link Terminals and mixed-I/O B7A Link Terminals with 8 inputs and 8 outputs cannot
be connected to B7A Interface Units. Use 16-point B7A Link Terminals. The 16-point B7A Link Terminals
include 16-point (non-mixed) Terminals, 32-point Terminals configured with two 16-point circuits, and
mixed-I/O Terminals with 16 inputs and 16 outputs.
Comparison between Standard and Group-2 B7A Interface Units
Type Models Word allocations
Connectable B7A Link Terminals
yp
Transmission
delay
Transmission
errors
Points
Standard
C200H-B7AI1
Same as I/O Units (in order
mounted)
Standard
types only
Input status
held
16-point
Terminals only
C200H-B7AO2
moun
t
e
d)
.
t
ypes on
l
y
(19.2 ms)
h
e
ld
automatically
T
erm
i
na
l
s on
l
y
(see note 2)
Group-2
C200H-B7A12
Words 030 to 049 allocated
according to I/O number setting
Standard
(19 2 ms) and
Switch setting
to hold or
()
C200H-B7A02
according to I
/O
number setting
(same as Group-2 High-density I/O
(
19.2 ms
)
and
high-speed
to hold or
reset Input
C200H-B7A21
(same as Group 2 High density I/O
Units)
high speed
(3 ms) types
(set via
reset Input
status.
C200H-B7A22
(set via
switch)
Note 1. Mount the C200H-B7AO1 B7A Interface Unit to the C200H-BCjj1-V1 or C200H-BCjj1-V2 Back-
plane.
2. The 10-point B7A Link Terminals and mixed-I/O B7A Link Terminals with 8 inputs and 8 outputs cannot
be connected to B7A Interface Units. The 16-point (non-mixed) Terminals, 32-point Terminals config-
ured with the two 16-point circuits, and mixed-I/O Terminals with 16 inputs and 16 outputs can be con-
nected.
