Page #202 background imageLoading...
Page #202 background image
Appendix BSpecifications
188
Specifications
Item C200H-B7A12 C200H-B7A02 C200H-B7A21 C200H-B7A22
I/O points 32 input points or
30 input points and 2
error inputs
32 output points 16 output points and
16 input points or
15 input points + 1
error input
32 output points and
32 input points or
30 input points + 2
error inputs
Transmission
method
One-way distributed multiplex transmission
Transmission
distance (see
note 1)
Standard: 500 m max.
High-speed: 100 m max.
Transmission
delay
Standard: Typ. 19.2 ms, 31 ms max.
High-speed: Typ. 3 ms, 5 ms max.
Minimum input
time (see note
2)
Standard: 16 ms
High-speed: 2.4 ms
Internal current
consumption
5 VDC, 100 mA max.
External power
supply (see
12 to 24 VDC ±10%
supp
l
y
(
see
note 3)
0.05 A min. 0.06 A min. 0.05 A min. 0.08 A min.
Weight 300 g max.
Dimensions 35 x 130 x 128 mm (W x H x D)
Note 1. The transmission distance also depends on whether a common or separate power supplies are used.
2. The minimum input time refers to the minimum time required for reading the input signals from the CPU.
The ON/OFF width of the signal transmitted from the CPU to the output relay of the B7A Interface Unit
should be set to a value larger than the minimum input time.
3. The capacity of the external power supply does not include the capacity required by the B7A Link Termi-
nal.
Maximum Current and Power Supplied
There are limits to the current and power that can be supplied to each Rack and Unit. When designing the system,
take the current consumption into account.
Follow the chart below and be careful that the total current consumption does not exceed the maximum current
and maximum total power supplied.
Current Supplied
Name Model number Max. current supplied Maximum power
supplied
5 V
(internal logic
current)
26 V
(relay drive
current)
24 V
(No-voltage
contact current)
CPU Rack C200HS-CPU01-E/
CPU01-EC/CPU21-E/
CPU21-EC/CPU31-E
3.9 A 0.6 A 0.8 A 23.5 to 26.5 W
(See conditions
below.)
C200HS-CPU03-E/
CPU23-E/CPU33-E
2.3 A 0.6 A --- 21.5 W
Expansion
I/O Rack
C200H-PS221/
PS221-C
2.7 A 0.6 A 0.8 A 28 W
I/O Rack
C200H-PS211 --- 23 W
Slave Rack C200H-RT001-P 2.7 A 0.6 A 0.8 A 28 W
C200H-RT002-P --- 23 W
C200H-RT201 0.8 A 28 W
C200H-RT202 --- 23 W
