Appendix BSpecifications
191
Unit Current
consumption
Model number
Transistor Output C200H-OD411 0.14 A
C200H-OD211 0.16 A
C200H-OD212 0.18 A
C200H-OD213 0.14 A
C200H-OD214
C200H-OD216 0.01 A each
C200H-OD217
C200H-OD21A 0.16 A
Triac Output
C200H-OA121-E 0.14 A
p
C200H-OA122-E 0.18 A
C200H-OA221 0.14 A
C200H-OA223 0.18 A
C200H-OA222V 0.20 A
C200H-OA224 0.27 A
Analog Timer C200H-TM001 0.06 A
Standard B7A Interface C200H-B7AI1 0.10 A
C200H-B7AO1
Interrupt Input C200HS-INT01 0.02 A
Unit Model number Current
consumption
DC Input
C200H-ID111 0.12 A
p
C200H-ID216 0.1 A
C200H-ID217 0.12 A
C200H-ID218 0.1 A
C200H-ID219 0.12 A
Transistor Output
C200H-OD218 0.18 A
p
C200H-OD219 0.27 A
C200H-OD21B 0.18 A
Unit Model number Current
consumption
B7A Interface Unit
(G 2 U i )
C200H-B7A12/02 0.10 A
(Group-2 Units)
C200H-B7A21/22
Unit Model number Current
consumption
TTL Input C200H-ID501 0.13 A
DC Input C200H-ID215
TTL Output C200H-OD501 0.22 A
Transistor Output C200H-OD215
TTL I/O C200H-MD501 0.18 A
DC Input/Transistor C200H-MD115
Output C200H-MD215
High-speed Counter C200H-CT001-V1 0.30 A
C200H-CT002
Position Control C200H-NC111
0.15 A
C200H-NC112
C200H-NC211 0.50 A
Analog Input C200H-AD001 0.55 A
C200H-AD002 0.45 A
Current Drawn from 5-V
Supply for Group-2
High-density I/O Units
Current Drawn from 5-V
Supply for Group-2 B7A
Interface Units
Current Drawn from 5-V
Supply for Special I/O Units
