31
4. Used when pin 1 is ON, setting the C200H-OD501/OD215 to dynamic out-
put mode.
I/O Unit lock notch
Nameplate
I/O indicators:
Indicate ON/OFF status of points
24-pin connectors
Unit number setting switch
I/O Units Section 2-5
