ix
About this Manual:
This manual describes the installation of C200HS Programmable Controllers, and it includes the sections
described below. Programming and operating information is provided in the C200HS Operation Manual.
Please read this manual completely and be sure you understand the information provided before attempt-
ing to install a C200HS PC. Be sure to read the precautions in the following section.
Section 1 is an introduction to Programmable Controllers (or PCs). General information is provided on
PCs and how they work. This section also provides an overview of the new features of the C200HS and
the major differences between the C200HS and the C200H.
Section 2 provides a description of all the components of the C200HS. The names of all the individual
parts of each Unit are given.
Section 3 describes how to install a PC System, including mounting the various Units and configuring the
System.
Section 4 provides the information necessary to wire a C200HS System.
Section 5 provides general information about the Programming Console, LSS, SSS, and ways in which
the C200HS System can be expanded for more versatility.
Section 6 provides information on hardware and software errors that occur during PC operation. It also
provides troubleshooting charts for CPU Racks, Expansion I/O Racks, Input Units, and Output Units.
Section 7 covers maintenance and inspection, and explains how to replace consumable components
such as fuses, relays, and batteries.
Appendixes, a Glossary, and an Index are also provided.
WARNING Failure to read and understand the information provided in this manual may result in
personal injury or death, damage to the product, or product failure. Please read each
section in its entirety and be sure you understand the information provided in the section
and related sections before attempting any of the procedures or operations given.
!
