When inputting an SV as a constant, CONT/# is not required; just input the
numeric value and press WRITE. To designate a word, press CLR and then
input the word address as described above.
The most basic instructions are input using the Programming Console keys
provided for them. All other instructions are input using function codes.
These function codes are always written after the instruction’s mnemonic. If
no function code is given, there should be a Programming Console key for
that instruction.
To input an instruction word using a function code, set the address, press
FUN, input the function code including any leading zero, input any bit oper-
ands or definers required on the instruction line, and then press WRITE.
Enter function codes with care.
The following ladder diagram can be input using the key inputs shown below.
Displays will appear as indicated.
Address Instruction Data
0200 LD 0002
0201 TIM 00
#0123
0202 TIMH(15) 01
#0500
Designating Instructions
Note
Example
Inputting, Modifying, and Checking the Program Section 7–5
