80
Sensor
Chute
(0002)
(0500)
Sensor
(0001)
Rotary Encoder
(0000)
Pusher
I
P
SFT(10)
HR 0
HR 1
R
0001
0000
0003
0500
HR 003
0002
HR 003
0500
5–12–2 Word Shift – WSFT(16)
St : Start word
IR, DM, HR
E : End word
IR, DM, HR
Ladder Symbols Operand Data Areas
WSFT(16)
St
E
St and E must be in the same data area and St must be less than E.
When the execution condition is OFF, WSFT(16) is not executed and the
next instruction is moved to. When the execution condition is ON, 0000 is
moved into St, the content of St is moved to St + 1, the content of St + 1 is
moved to St + 2, etc., and the content of E is lost.
Limitations
Description
Data Shifting Section 5–12
To Next Page
