Omron SYSMAC C20P User Manual

Standard Models Appendix A
158
• U: UL, C: CSA, N: NK
See Omron sales representatives concerning operating conditions
under which UL, CSA, and NK standards were met (Aug. 1988).
CPUs
Name Power supply Inputs Outputs Model number Standards
C20P 100 to 240 VAC 24 VDC, 12 pts. Relay with socket 8 pts. C20P–CDR–AE U, C
Transistor, 0.5 A C20P–CDT–AE U, C
Transistor, 1 A C20P–CDT1–AE U
Triac, 1 A C20P–CDS1–AE U, C
24 VDC, 2 pts.
100 VAC, 10 pts.
Relay with socket C20P–CAR–AE U, C
24 VDC 24 VDC, 12 pts. Relay with socket C20P–CDR–DE U, C
Transistor, 0.5 A C20P–CDT–DE U
Transistor, 1 A C20P–CDT1–DE
U
C28P 100 to 240 VAC 24 VDC, 16 pts. Relay with socket 12 pts. C28P–CDR–AE U, C
Transistor, 0.5 A C28P–CDT–AE U, C
Transistor, 1 A C28P–CDT1–AE U, C
Triac, 1 A C28P–CDS1–AE U, C
24 VDC, 2 pts.
100 VAC, 14 pts.
Triac, 1A C28P–CAS1–AE U, C
24 VDC 24 VDC, 24 pts. Relay with socket C40P–CDR–DE U, C
Transistor, 0.5 A C28P–CDT–DE U
Transistor, 1 A C28P–CDT1–DE U
C40P 100 to 240 VAC 24 VDC, 24 pts. Relay with socket 16 pts. C40P–CDR–AE U, C
Transistor, 0.5 A C40P–CDT–AE –––
Transistor, 1 A C40P–CDT1–AE U, C
Triac, 1 A C40P–CDS1–AE U, C
24 VDC, 2 pts. Relay with socket C40P–CAR–AE C
100 VAC, 22 pts. Triac, 1 A C40P–CAS1–AE U, C
24 VDC 24 VDC, 24 pts. Relay with socket C40P–CDR–DE U, C
Transistor, 0.5 A C40P–CDT–DE U
Transistor, 1 A C40P–CDT1–DE U
C60P 100 to 240 VAC 24 VDC, 32 pts. Relay with socket 28 pts. C60P–CDR–AE –––
Transistor, 1 A C60P–CDT1–AE –––
Triac, 1 A C60P–CDS1–AE –––
24 VDC, 2 pts. Relay with socket C60P–CAR–AE –––
100 VAC, 30 pts. Triac, 1 A C60P–CAS1–AE –––
24 VDC 24 VDC, 32 pts. Relay with socket C60P–CDR–DE –––
Transistor, 1 A C60P–CDT1–DE –––
