23
IR 00
IR 05
IR 01
IR 06
IR 02
IR 07
IR 03
IR 08
IR 04
IR 09
C40P/C60P
Input
Output
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C40P/C60P
Input
Output
Input
Output
C40P/C60P
Input
Output
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C40P/C60P
Input
Output
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C40P/C60P
Input
Output
Input
Output
C20P/C28P/TU/AN/LU
Input
Output
C4K/C16P
Input or Output
C4K/C16P
Input or Output
C4K/C16P
Input or Output
C4K/C16P
Input or Output
C4K/C16P
Input or Output
C4K/C16P
Input or Output
C4K/C16P
Input or Output
C4K/C16P
Input or Output
IR Area
Section 3–3
31
33
