Unit Input word Output word
CPU 00 01
Analog Timer Unit 02 03
All four time’s are used. Times for two of them are adjusted on the variable
resistors provided on the Analog Timer Unit. The other two times are ad-
justed using external resistors. These adjustments are made as follows. Re-
fer to the
Analog Timer Unit Installation Guide
for hardware details.
Timer
SV Range Resistor adjustment
T
0
Approx. 0.6 s 0.1 to 1 s 6/10th turn clockwise
T
1
Approx. 3 s 1 to 10 s 3/10th turn clockwise
T
2
Approx. 2.6 s 10 to 60 s 2/10th turn clockwise
T
3
Approx. 8 min 1 to 10 min 8/10th turn clockwise
The following program sections are used to set up the required data and pro-
duce outputs from the four timers. The first section moves E400 into IR 06 to
set the desired ranges (see table above). The second program section
achieves the following operation.
1. IR 0500 is turned ON approximately 0.6 seconds after IR 0002 turns ON
as the result of the action of T
0
.
2. IR 0501 is turned ON approximately 3 seconds after IR 0003 turns ON
as the result of the action of T
1
.
3. IR 0502 is turned ON approximately 20 seconds after IR 0004 turns ON
as the result of the action of T
2
.
4. IR 0503 is turned ON approximately 8 minutes after IR 0004 turns ON
as the result of the action of T
3
.
5. T
2
and T
3
are made inoperative if IR 0015 is turned ON.
MOV(21)
#E400
06
1815
First Scan Flag
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
1110010000000000
Content of IR O6 after MOV(21)
Range settings
Programming
1, 2, 3...
Timer and Counter Instructions Section 5–11
To Next Page
