134
Description of Operation Section 3-2
For this reason, if the wrong unit number on the Field Terminals is set, the
wrong data will be written to the allocated CIO area of the Special I/O Unit
having that unit number, and may cause the overall PLC system to mal-
function.
Before starting running of the Loop Controller, first make sure that the unit
number on the Field Terminals matches that set on the front panel of the
Analog Input/Output Unit.
Field Terminals that undergo writing by the Loop Controller
Model Function
block name
Target Analog
Input/Output
Unit
Internal writing by
Loop Controller
Writing of analog
values
552 AO 8-point Ter-
minal
(DA003/4)
C200H-
DA003/004
00FF Hex is stored
to leading allo-
cated word (n).
Analog value is
stored to allocated
area n+1 to n+8.
553 AI 2-point/AO
2-point Termi-
nal (MAD01)
C200H-MAD01 0003 Hex is stored
to leading allo-
cated word (n).
Analog value is
stored to allocated
area n+1 to n+2.
583 AI 4-point/AO
4-point Termi-
nal (MAD44)
CS1W-MAD44 000F Hex is stored
to leading allo-
cated word (n).
Analog value is
stored to allocated
area n+1 to n+4.
563 AO 4-point Ter-
minal (PMV01)
CS1W-PMV01
(isolated-type
control output)
None Analog value is
stored to allocated
area n+1 to n+4.
585 AO 8-point Ter-
minal
(DA08V/C)
CS1W-
DA08V/C
00FF Hex is stored
to leading allo-
cated word (n).
Analog value is
stored to allocated
area n+1 to n+8.
587 AO 4-point Ter-
minal (DA041)
CS1W-DA041 000F Hex is stored
to leading allo-
cated word (n).
Analog value is
stored to allocated
area n+1 to n+4.
565 AO 4-point Ter-
minal (PMV02)
CS1W-PMV02
(isolated-type
control output)
None Analog value is
stored to allocated
area n+1 to n+4.
591 AO 2-point Ter-
minal (DA021)
CJ1W-DA021 0003 Hex is stored
to leading allo-
cated word (n).
Analog value is
stored to allocated
area n+1 to n+2.
592 AI 4-point/AO
2-point Termi-
nal (MAD42)
CJ1W-MAD42 0003 Hex is stored
to leading allo-
cated word (n).
Analog value is
stored to allocated
area n+1 to n+2.
To Next Page
