135
Description of Operation Section 3-2
Note Field Terminals that do not undergo writing by the Loop Controller
Model Function
block name
Target Analog Input/Output
Unit
Internal
writing by
Loop
Controller
Writing of
analog
values
551 AI 8-point Ter-
minal (AD003)
C200H-AD003 None None
561 AI 4-point Ter-
minal
(PTS01/02/03/
11/12,
PDC01/11,
PTW01)
CS1W-PTS01/PTS11 (iso-
lated-type thermocouple input),
CS1W-PTS02/03/12 (isolated-
type temperature-resistance
thermometer),
CS1W-PDC01/11 (isolated-
type analog input),
CS1W-PTW01 (2-wire trans-
mitter input)
562 AI 4-point Ter-
minal (PPS01)
CS1W-PPS01 (isolated-type
pulse input)
564 AI 8-point Ter-
minal
(PTR01/02)
CS1W-PTR01 (Power Trans-
ducer Input Unit), CS1W-
PTR02 (analog input 100 mV)
566 AI 4-point Ter-
minal (PTS51)
CS1W-PTS51/CJ1W-PTS51
(isolated-type thermocouple
input)
567 AI 4-point Ter-
minal (PTS52)
CS1W-PTS52/CJ1W-PTS52
(isolated-type temperature
resistance thermometer input)
568 AI 8-point Ter-
minal (PTS55)
CS1W-PTS55 (isolated-type
thermocouple input)
569 AI 8-point Ter-
minal (PTS56)
CS1W-PTS56 (isolated-type
temperature resistance ther-
mometer input)
570 AI 8-point Ter-
minal (PDC55)
CS1W-PTS56 (isolated-type
analog input)
571 AI 2-point Ter-
minal
(PRS15/16,
PDC15)
CJ1W-PTS15 (isolated-type
thermocouple input), CJ1W-
PTS16 (isolated-type tempera-
ture resistance thermometer
input), CJ1W-PDC15 (isolated-
type analog input)
572 AI 4-point Ter-
minal (PH41U)
CJ1N-PH41U Isolated-type
High-resolution Analog Input
Unit with Fully Universal Inputs
573 AI 4-point Ter-
minal (AD04U)
CJ1W-AD04U Isolated-type
General-purpose Analog Input
Unit with Fully Universal Inputs
581 AI 4-point Ter-
minal (ADG41)
CJ1W-ADG41 High-speed
Analog Input Unit
582 AI 16-point Ter-
minal (AD161)
CS1W-AD161
584 AI 8-point Ter-
minal (AD081)
CS1W-AD081
586 AI 4-point Ter-
minal (AD041)
CS1W-AD041
To Next Page
