Omron SYSMAC CS Series User Manual

196
Examples of Applied Control Types Section 5-2
Example
PID2
PV
MV compensation
(addition)
PID1
MV 2
PV
Lead/delay
operation
Vapor
Fuel
Analog
output
Analog
input
021
007
Lead/delay operation
<Block Model 147>
Address 100
013
Advanced PID
<Block Model 012>
087
MV
PV
MV
compensation
022
Disturbance
074
006
021
Address 001
Block
address
ITEM No. Data Explanation
901 002 586 AI 4-point Terminal block
021 Y1 (analog input 1)
022 Y2 (Analog input 2)
902 002 587 AO 4-point terminal block
021 001087 X1 (analog output 1) source designa-
tion
031 X1 (analog output 1)
001 002 012 Advanced PID block
006 901021 PV source designation
074 100013 MV compensation (addition)
087 MV
002 002 147 Lead/delay operation blocks
007 901022 X1 source designation
009 K (gain) 0 to 10.000
010 T1 (lead time constant) 0 to 999.9 s
011 T2 (delay time constant) 0 to 999.9 s
013 Y1 output value
