How to Use the Sequence Table Block Appendix B
Only Rules Column Expanded
Note To expand the number of rules in a table, use the CX-Process Tool and select Expand - Horizontal from
the Operation Menu.
Both Conditions/Actions and Rules Columns Expanded
Note To expand both the number of conditions/actions and the number of rules in a table, use the CX-Process
Tool and select Expand - Vertical as well as Expand - Horizontal from the Operation Menu.
Table Referencing (LCB01/03/05 Ver. 3.0 or Later)
Overview
The table referencing function enables a main sequence table (called the main table) to reference the evalua-
tion results of the condition rules for a reference destination sequence tables (called the reference table).
This function enables common processing to be placed in reference tables. The TBL command (specifies the
block address of the reference table) is entered as the input signal condition, and Y (input as is) or N (reverse
input) is entered as the rule.
Table number
Rule 1 2 64
Symbol
Step 00
64 max.
THEN To M
NEXT STEP
ELSE
32 actions
max.
64 rules max. and 64 steps max.
32 conditions
max.
Table number
Table number
LCB05/05D: 100 tables max.
Condition rule 2 Condition rule 1
Condition
signals
Action rule 2 Action rule 1
Condition rule
64
Action rule
64
Action
signals
Table number
Rule 1 2 - - - 64
Symbol
Step 00 - - - 64 max.
THEN To M
NEXT STEP
ELSE
64 actions
max.
64 rules max. and 64 steps max.
64 conditions
max.
Table number
Table number
LCB05/05D: 50 tables max.
Condition rule 2 Condition rule 1
Condition
signals
Action rule 2 Action rule 1
Condition rule
64
Action rule
64
Action
signals
