Omron SYSMAC CS Series User Manual

31
Outline Section 1-1
Field Termi-
nal
Analog
I/O
564
(See notes
1 and 5.)
AI 8-point Termi-
nal (PTR01/02)
Inputs 8 analog signals from CS1W-PTR01
(Power Transducer Input Unit) or CS1W-
PTR02 (Analog Input Unit (100 mV)).
901 to 980
565
(See notes
1 and 5.)
AO 4-point Ter-
minal (PMV02)
Outputs 4 analog signals from CS1W-
PMV02 (Isolated-type Control Output Unit).
566
(See note
4.)
AI 4-point Termi-
nal (PTS51)
Inputs 4 analog signals from CS1W-PTS51
or CJ1W-PTS51
(Isolated-type Thermocouple Input Unit).
567
(See note
4.)
AI 4-point Termi-
nal (PTS52)
Inputs 4 analog signals from CS1W-PTS52
or CJ1W-PTS52
(Isolated-type Thermocouple Input Unit).
568
(See notes
4 and 5.)
AI 8-point Termi-
nal (PTS55)
Inputs 8 analog signals from CS1W-PTS55
(Isolated-type Thermocouple Input Unit).
569
(See notes
4 and 5.)
AI 8-point Termi-
nal (PTS56)
Inputs 8 analog signals from CS1W-PTS56
(Isolated-type Thermocouple Input Unit).
570
(See notes
4 and 5.)
AI 8-point Termi-
nal (PDC55)
Inputs 8 analog signals from CS1W-PDC55
(Direct current Input Unit).
571
(See note
7.)
AI 2-point Termi-
nal (PTS15/16,
PDC15)
Inputs 2 analog outputs from CS1W-
PTS15, CS1W-PTS16, or CS1W-PDC15.
572
(See notes
6 and 7.)
AI 4-point Termi-
nal (PH41U)
Inputs 4 analog signals from CJ1W-PH41U
(Isolated-type High-resolution Analog Input
Unit with Fully Universal Inputs)
573
(See notes
6 and 7.)
AI 4-point Termi-
nal (AD04U)
Inputs 4 analog signals from CJ1W-AD04U
Isolated-type General-purpose Input Unit
with Fully Universal Inputs)
581
(See notes
6 and 7.)
AI 4-point Termi-
nal (ADG41)
Inputs 4 analog signals from CJ1W-ADG41
(High-speed Analog Input Unit)
582
(See note
7.)
AI 16-point Ter-
minal (AD161)
Inputs 16 analog outputs from CS1W-
AD161.
583
(See notes
1 and 5.)
AI 4-point/AO 4-
point Terminal
(MAD44)
Inputs and outputs 4 analog signals each
from the CS1W-MAD44.
584
(See note
1.)
AI 8-point Termi-
nal (AD081)
Inputs 8 analog signals from the CS1W-
AD081(-V) or CJ1W-AD081(-V).
585
(See note
1.)
AO 8-point Ter-
minal
(DA08V/C)
Outputs 8 analog signals from the CS1W-
DA08V/DA08C or CJ1W-DA08V/DA08C.
586
(See note
1.)
AI 4-point Termi-
nal (AD041)
Inputs 4 analog signals from the CS1W-
AD041(-V1) or CJ1W-AD041(-V1)
587
(See note
1.)
AO 4-point Ter-
minal (DA041)
Outputs 4 analog signals from the CS1W-
DA041 or CJ1W-DA041.
588
(See note
1.)
AI 4-point Termi-
nal (DRT1-
AD04)
Inputs four analog signals from a DRT1-
AD04 DeviceNet Slave Analog Input Unit.
589
(See note
1.)
AO 2-point Ter-
minal (DRT1-
DA02)
Outputs two analog signals from a DRT1-
DA02 DeviceNet Slave Analog Output Unit.
591
(See notes
4 and 5.)
AO 2-point Ter-
minal (DA021)
Outputs 4 analog signals from the CJ1W-
DA021.
592
(See notes
4 and 5.)
AI 4-point/AO 2-
point Terminal
(MAD42)
Inputs 4 analog signals and outputs 2 ana-
log signals each from the CJ1W-MAD42.
Category Type Block
Model
Block Name Function Allocatable Block
Address
