Omron SYSMAC CS Series User Manual

30
Outline Section 1-1
Field Termi-
nal
Contact
I/O
501
(See note
1.)
DI 8-point Ter-
minal
Inputs 8 contacts from 8-point Input Unit. 901 to 980
502
(See note
1.)
DI 16-point Ter-
minal
Inputs 16 contacts from 16-point Input Unit.
503
(See note
1.)
DI 32-point Ter-
minal
Inputs 32 contacts from 32-point Input Unit.
504
(See note
1.)
DI 64-point Ter-
minal
Inputs 64 contacts from 64-point Input Unit.
511
(See note
1.)
DO 5-point Ter-
minal
Outputs 5 contacts from 5-point Output
Unit.
512
(See note
1.)
DO 8-point Ter-
minal
Outputs 8 contacts from 8-point Output
Unit.
513
(See note
1.)
DO12-point Ter-
minal
Outputs 12 contacts from 12-point Output
Unit.
514
(See note
1.)
DO16-point Ter-
minal
Outputs 16 contacts from 16-point Output
Unit.
515
(See note
1.)
DO32-point Ter-
minal
Outputs 32 contacts from 32-point Output
Unit.
516
(See note
1.)
DO64-point Ter-
minal
Outputs 64 contacts from 64-point Output
Unit.
518
(See note
1.)
DI 16-
point/Do16-point
Terminal
Inputs and outputs 16 contacts each from
16-point Input/16-point Output Units.
525
(See note
1.)
DI 96-point Ter-
minal
Inputs 96 contacts from 96-contact Input
Units.
537
(See note
1.)
DO 96-point Ter-
minal
Outputs 96 contacts from 96-contact Out-
put Units.
544
(See note
1.)
DI 48-point/DO
48-point Termi-
nal
Inputs and outputs 48 contacts each from
48-point Input/48-point Output Units.
Analog
I/O
551
(See note
1.)
AI 8-point Termi-
nal (AD003)
Inputs 8 analog signals from the C200H-
AD003.
901 to 980
552
(See note
1.)
AO 8-point Ter-
minal (DA003/4)
Inputs 8 analog signals from the C200H-
DA003/DA003.
553
(See note
1.)
AI 2-point/AO 2-
point Terminal
(MAD01)
Inputs and outputs 2 analog signals each
from the C200H-MAD01.
561
(See notes
1 and 5.)
AI 4-point Termi-
nal
(PTS01/02/03,P
DC01, PTW01)
Inputs 4 analog signals from one of CS1W-
PTS01 (Isolated-type Thermocouple Input
Unit), CS1W-PTS02/03 (Isolated-type Tem-
perature-resistance Thermometer Input
Unit), CS1W-PDC01 (Isolated-type Analog
Input Unit) or CS1W-PTW01 (2-lead Trans-
mitter Input Unit).
562
(See notes
1 and 5.)
PI 4-point Termi-
nal (PPS01)
Inputs 4 instantaneous values and accumu-
lated values each from CS1W-PPS01 (Iso-
lated-type Pulse Input Unit).
563
(See notes
1 and 5.)
AO 4-point Ter-
minal (PMV01)
Outputs 4 analog signals from CS1W-
PMV01 (Isolated-type Control Output Unit).
Category Type Block
Model
Block Name Function Allocatable Block
Address
