Omron SYSMAC CS Series User Manual

34
Outline Section 1-1
Function
blocks
Max. number of
registered Blocks
Control Blocks: 32
Operation Blocks:
249
The total number of
Control Blocks and
Operation Blocks is
limited as follows:
LCB01: 50 Blocks
max.
LCB05: 500 Blocks
max.
The total number of
Fuzzy Logic Blocks
(Block Model 016),
Arithmetic Opera-
tion Blocks (Block
Model 126), and
Time Sequence
Data Statistics
Blocks (Block Model
153) is limited to
100 Blocks max.
The total number of
Control Blocks and
Operation Blocks is
limited to 500
Blocks max.
External Controller
Terminal Blocks
(Block Model 045)
are not supported.
The total number of
Fuzzy Logic Blocks
(Block Model 016),
Arithmetic Opera-
tion Blocks (Block
Model 126), and
Time Sequence
Data Statistics
Blocks (Block Model
153) is limited to
100 Blocks max.
The total number of
Control Blocks and
Operation Blocks is
limited as follows:
LCB01: 50 Blocks
max.
LCB03: 300 Blocks
max.
External Controller
Terminal Blocks
(ES100X Controller
Terminal (Block
Model 045)) are not
supported.
The total number of
Fuzzy Logic Blocks
(Block Model 016),
Arithmetic Opera-
tion Blocks (Block
Model 126), and
Time Sequence
Data Statistics
Blocks (Block Model
153) is limited to
100 Blocks max.
Types of Function
Blocks
Step Ladder Pro-
gram
Step Ladder Program or sequence table (cannot be used
together)
(Note: LCB01 and LCB03 support step ladder programming
only.)
ES100X Controller
Ter min al
ES100X Controller
Ter mi nal
Not supported
DI Terminal from
CPU Unit
User link table
DO Terminal to
CPU Unit
AI Terminal from
CPU Unit
AO Terminal from
CPU Unit
Expanded DI Ter-
minal from CPU
Unit
Expanded DO Ter-
minal from CPU
Unit
Expanded AI Ter-
minal from CPU
Unit
Expanded AO Ter-
minal from CPU
Unit
Receive All Blocks HMI function
(HMI-related ITEM settings for System Common Block)
Send All Blocks
4-Point Warning
Indicator
None (Combined with the Indicator Block (Block Model 034.))
Area Item Loop Control
Unit
Loop Control
Board
Process-control
CPU Unit
Loop-control CPU
Unit
