Configuration of Instrumentation System Section 1-2
CS Series
Unit
information
Name Specification Model Function block
CS-series Spe-
cial I/O Unit
Analog Input/Out-
put Unit
4 inputs (1 to 5 V, 4 to 20 mA, etc.)
4 outputs (1 to 5 V, 0 to 10 V, etc.)
CS1W-MAD44 AI 4-point/AO 4-point
Terminal (Block
Model 583)
Analog Input Unit 4 inputs (1 to 5 V, 4 to 20 mA, etc.) CS1S-AD041 AI 4-point Terminal
(Block Model 586)
8 inputs (1 to 5 V, 4 to 20 mA, etc.) CS1S-AD081 AI 8-point Terminal
(Block Model 584)
16 inputs (1 to 5 V, 4 to 20 mA, etc.) CS1W-AD161 AI 16-point Terminal
(Block Model 582)
Analog Output Unit 4 outputs (1 to 5 V/4 to 20 mA, etc.) CS1W-DA041 AO 4-point Terminal
(Block Model 587)
8 outputs (1 to 5 V, etc.) CS1W-DA08V AO 8-point Terminal
(Block Model 585)
8 outputs (4 to 20 mA) CS1W-DA08C AO 8-point Terminal
(Block Model 585)
Isolated-type Ther-
mocouple Input
Unit
4 inputs (B, E, J, K, N, R, S, T,
DC±80 mV)
CS1W-PTS01-V1 AI 4-point Terminal
(Block Model 561)
4 inputs (B, E, J, K, L, N, R, S, T, U,
WRe5-26, PLII, mV)
CS1W-PTS11 Not supported
4 inputs (K, J, L, R, S, T, B) CS1W-PTS51 Ai 4-point Terminal
(Block Model 566)
8 inputs (K, J, L, R, S, T, B) CS1W-PTS55 Ai 8-point Terminal
(Block Model 568)
Isolated-type Tem-
perature-resis-
tance Thermometer
Input Unit
4 inputs (Pt100, JPt) CS1W-PTS02 AI 4-point Terminal
(Block Model 561)
4 inputs (Ni508.4Ω) CS1W-PTS03 AI 4-point Terminal
(Block Model 561)
4 inputs (Pt100, JPt100, Pt50,
Ni508.4Ω)
CS1W-PTS12 Not supported
4 inputs (Pt100, JPt100) CS1W-PTS52 Ai 4-point Terminal
(Block Model 567)
8 inputs (Pt100, JPt100) CS1W-PTS56 AI 8-point Terminal
(Block Model 569)
Isolated-type 2-lead
Transmitter Input
Unit
4 inputs (1 to 5 V, 4 to 20 mA), built-
in power supply for 2-lead Transmit-
ter
CS1W-PTW01 AI 4-point Terminal
(Block Model 561)
Isolated-type Ana-
log Input Unit
4 inputs (1 to 5 V, 4 to 20 mA, etc.) CS1W-PDC01 AI 4-point Terminal
(Block Model 561)
4 inputs (1 to 5 V, 4 to 20 mA, etc.) CS1W-PDC11 Not supported
8 inputs (1 to 5 V, 4 to 20 mA, etc.) CS1W-PDC55 AI 8-point Terminal
(Block Model 570)
Isolated-type Ana-
log Output Unit
(Analog Output
Unit)
4 outputs (1 to 5 V, 4 to 20 mA) CS1W-PMV01 AO 4-point Terminal
(Block Model 563)
4 outputs (−10 to 10 V, 0 to 10 V, −5
to 5 V, 1 to 5 V, −1 to 1 V, 0 to 1 V)
CS1W-PMV02 AO 4-point Terminal
(Block Model 565)
Power Transducer
Input Unit
8 inputs (−1 to 1 mA, 0 to 1 mA) CS1W-PTR01 AI 8-point Terminal
(Block Model 564)
Analog Input Unit
(100 mV)
8 inputs (−100 to 100 mA,
0 to 100 mA)
CS1W-PTR02 AI 8-point Terminal
(Block Model 564)
Isolated-type Pulse
Input Unit
4 pulse inputs (0 to 20 Kpulses/s,
0 to 20 pulses/s)
CS1W-PPS01 PI 4-point Terminal
(Block Model 562)
