55
Specifications Section 1-3
Internal
Opera-
tion
Number of control
loops
The maximum number of loops that can be used if the LCB load rate is 80% for a stan-
dard applications (e.g., with each loop consisting of one Ai4 Terminal, Segment Linear-
izer, Basic PID, and A04 terminal) is shown in the following table.
Number of opera-
tions for process
(excluding control)
LCB01: Max. 50 blocks
LCB03: Max. 30 blocks
LCB05: Max. 500 blocks
Sequen-
tial control
(Use only
one or the
other)
Step lad-
ders
LCB01: 20 blocks per Board and total max. 2,000 commands per Board
LCB03/05/05D: 200 blocks per Board and total max. 4,000 commands per Board
Loop Controllers common: Divisible to 100 commands max. per block and 100 steps
max. per block (100 commands max. per step)
Sequence
tables
Sequence tables: 200 max. (LCB05 and 05D only)
Control
method
PID control PID with two degrees of freedom
Possible control type
combinations
Basic PID control, cascade control, feedforward control, sample PI control, dead time
compensation, PID control with differential gap, override control, program control, time-
proportional control and other control types can be achieved by combining function
blocks.
Alarm Integrated into PID
block
4 PV alarms (high/high limit, high limit, low limit, low/low limit) per PID block, 1 deviation
alarm
Alarm block High/Low Alarm block, Deviation Alarm block
Internal analog signal Min. −320.00% to max. +320.00%
Scaling of the engineering units depends on the CX-Process Tool (sold separately).
Operating status monitor
method
Executed by commercially available SCADA software. In the SCADA software, tags set
on the CX-Process Tool are specified.
Item Description
CS1W-LCB01/05 (LCCB01/05)
CS1D-CPU@@P (LCB05D)
CJ1W-CPU43P/44P/45P (LCB03)
CJ1W-CPU42P (LCB01)
Operation cycle: Maximum number of loops
0.01 s: 20 loops 0.02 s: 35 loops 0.05 s: 70 loops
0.1 s: 100 loops 0.2 s: 180 loops 0.5 s: 250 loops
1 s: 250 loops 2 s: 250 loops
Operation cycle: Maximum number of loops
0.1 s: 80 loops 0.2 s: 140 loops 0.5 s: 250 loops
1 s: 250 loops 2 s: 250 loops
Operation cycle: Maximum number of loops
0.01 s: 20 loops 0.02 s: 35 loops 0.05 s: 70 loops
0.1 s: 100 loops 0.2 s: 150 loops 0.5 s: 150 loops
1 s: 150 loops 2 s: 150 loops
Operation cycle: Maximum number of loops
0.01 s: 20 loops 0.02 s: 25 loops 0.05 s: 25 loops
0.1 s: 25 loops 0.2 s: 25 loops 0.5 s: 25 loops
1 s: 25 loops 2 s: 25 loops
