Omron SYSMAC CS1 User Manual

6-4SectionAR Area
81
Address Forced
set/reset
Controlled
by
DetailsFunctionBits
AR 09
08
High-speed
counter 2
commands
High-speed
Counter
Start Bit
Same as for high-speed counter 1
commands.
User Enabled
09 High-speed
Counter
Reset Bit
10 Measure-
ment Start
Bit (mea-
surement
mode 1)
Same as for high-speed counter 1
commands except that frequency
measurement is not possible with counter
2.
11 (Reserved by system.)
12 Range
Comparison
Result Clear
Bit
Same as for high-speed counter 1
commands.
13 to
15
(Reserved
by
system.)
--- ---
AR 10 00 to
15
High-speed
counter 1
monitor
data
Range
comparison
result
The instruction execution result that is
output when the CTBL instruction is
executed for a range comparison is stored
here.
Bits 00 to 15: ON for each condition (from 1
to 16) that is satisfied.
OFF: Condition not satisfied
ON: Condition satisfied
Unit
AR 11 00 to
15
Output bit
pattern
The output bit pattern that is output when
the CTBL instruction is executed for a
range comparison is stored here.
Note: When more than one condition is
satisfied, the logical OR of all the output
patterns that satisfy the conditions is set.
AR 12 00 to
15
High-speed
counter 2
monitor
dt
Range
comparison
result
Same as for high-speed counter 1 monitor
data.
AR 13 00 to
15
data
Output bit
pattern
