Omron SYSMAC CS1 User Manual

6-4SectionAR Area
83
Address Forced
set/reset
Controlled
by
DetailsFunctionBits
AR 18
00
Pulse Output 1 Status
Pulse Output
Completed Flag
OFF: Pulse output not
completed (stays OFF
during pulse output).
ON: Pulse output
completed (goes ON
at completion of pulse
output)
Unit Enabled
01 Number of
Pulses Specified
Flag
OFF: Number of
pulses has not been
set using PULS.
ON: Number of pulses
has been set using
PULS.
02 PLS2 Target
Frequency Not
Reached
OFF: Normal
ON: Pulse output has
decelerated without
reaching the target
frequency when PLS2
is executed or during
pulse output.
03 Target
Comparison in
Progress
OFF: Stopped
ON: In progress
04 Independent
Pulse Output In
Progress
OFF: No output, or
continuous output
ON: Output in
progress
05 Positioning In
Progress (PLS2)
OFF: Positioning not
in progress
ON: Positioning in
progress
06 Accelerating/
Decelerating
OFF: No output, or
output at a constant
frequency
ON: During
acceleration or
deceleration using
ACC or PLS2.
07 Pulse Output In
Progress
OFF: Pulse output
stopped
ON: Pulse output in
progress
