6-4SectionAR Area
84
Address Forced
set/reset
Controlled
by
DetailsFunctionBits
AR 18
08
Pulse Output 2 Status
Pulse Output
Completed Flag
Same as for Pulse
Output 1 Status.
Unit Enabled
09 Number of
Pulses Specified
Flag
Os
10 PLS2 Target
Frequency Not
Reached
11 Target
Comparison in
Progress
12 Independent
Pulse Output In
Progress
13 Positioning In
Progress (PLS2)
14 Accelerating/
Decelerating
15 Pulse Output In
Progress
AR 19
00
Pulse output 1
commands
PV Reset OFF: Pulse output 1
PV not reset
ON: Pulse output 1 PV
reset
User Enabled
01 Range
Comparison
Result Clear
OFF: The instruction
execution result
(AR 20) or the output
bit pattern (AR 21) that
is output when the
CTBL instruction is
executed for a range
comparison on the
pulse output PV is not
cleared.
ON: The instruction
execution result
(AR 20) or the output
bit pattern (AR 21) that
is output when the
CTBL instruction is
executed for a range
comparison on the
pulse output PV is
cleared.
02 to 07 (Reserved by system.)
08
Pulse output 2
d
PV Reset
Same as for pulse
1d
09
commands
Range
Comparison
Result Clear
output 1 commands.
10 to 15 (Reserved by system.)
