6-4SectionAR Area
86
Analog Outputs (CS1W-HCA22 Only)
Address Bits Function Details Controlled
by
Forced
set/reset
AR 14 00 to 15 Analog Output 1
Output Value
If END refresh is set as the analog output
method, the value set here by the user in
4-digit hexadecimal is output from analog
output 1 when analog output is refreshed.
If immediate refresh using instructions is set
as the analog output method, the value
output from analog output port 1 is stored
here in 4-digit hexadecimal for monitoring
when analog output is refreshed.
0 to 10 V, 0 to 5 V, 1 to 5 V:
FF38 to 1068 Hex
–10 to 10 V: EA84 to 157C Hex
Note 1: The analog output method (END
refresh or immediate refresh using
instructions) is specified in bits 00 to 07 of
DM 6630 in the Unit Setup Area (00 Hex:
END refreshing). The setting applies to both
analog outputs 1 and 2.
Note 2: The output signal range is specified
in DM 6613.
Immediate
refresh
using
instructions:
Unit
END
refresh:
User
Enabled
AR 15 00 to 15 Analog Output 2
Output Value
Same as above (except that analog output 2
is used for analog output and the output
signal range is set in DM 6614).
AR 16
00 Analog Output 1
Conversion Enable
Bit
ON: D/A conversion enabled (an analog
signal is output)
OFF: D/A conversion is not performed
(analog output is held at the value specified
in DM 6613 nd DM 6614)
User
01 Analog Output 2
Conversion Enable
Bit
i
n
DM
6613 an
d
DM
6614
)
Note: These bits are cleared when the
Customizable Counter Unit’s operating
mode is switched between RUN or
MONITOR mode and PROGRAM mode.
02 to 15 (Reserved by system.)
