6-4SectionAR Area
88
Address Forced
set/reset
Controlled
by
DetailsFunctionBits
AR 18
00 Analog Output 1
Adjustment Enable
ON: Adjustment enabled
OFF: Adjustment disabled
User Enabled
01 Analog Output 2
Adjustment Enable
u
Enabled in adjustment mode (DM 6631 in
Unit Setting Area set to 5A5A Hex).
02 Adjusted Mode
Adjustment Item
Specifies either the offset value or the gain
value as the item to be adjusted.
OFF: Offset value
ON: Gain value
The value specified here can be adjusted
with the Adjustment Up Bit or Adjustment
Down Bit.
03 (Reserved by system.)
04 Adjustment Up Bit While this bit is ON, the offset value or the
gain value increases by 1 (resolution) every
0.5 s.
05 Adjustment Down Bit While this bit is ON, the offset value or the
gain value decreases by 1 (resolution) every
0.5 s.
06 Adjustment Clear
(reset to factory
settings)
ON: Cleared.
OFF: Not cleared.
Enabled in adjustment mode (DM 6631 in
Unit Setting Area set to 5A5A Hex).
07 Adjustment Set The adjustment value is written when this bit
is turned ON after adjusting the value with
the Adjustment Up Bit and Adjustment
Down Bit.
08 Adjustment
Command Operation
Error
This flag turns ON when an operational
error, such as turning ON both the
Adjustment Up Bit and the Adjustment
Down Bit together, has been made.
Unit
09 to 14 (Reserved by system.)
15 Adjustment Mode
Operation
ON during adjustment mode (DM 6631 in
Unit Setting Area set to 5A5A Hex).
AR 19 00 to 15 Analog Output 1/
Analog Output 2
Setting Offset
Monitor
Enabled in adjustment mode (DM 6631 in
Unit Setting Area set to 5A5A Hex).
It is possible to write gain values and offset
values here directly without using the
Adjustment Up Bit or Adjustment Down Bit.
Offset values:
–10 to 10 V: FE0C to 01F4 Hex
Unit/User
AR 20 00 to 15 Analog Output 1/
Analog Output 2
Setting Gain Monitor
0 to 10 V, 0 to 5 V, 1 to 5 V:
FF38 to 00C8 Hex
Gain values:
–10 to 10 V: 1194 to 157C Hex
0 to 10 V, 0 to 5 V, 1 to 5 V:
0ED8 to 1068 Hex
