8-3SectionCycle Time
116
Code OFF execution time (µs)Conditions (Top: min.; bottom: max.)ON
execution
time (µs)
Mnemonic
15 TIMH
Reset IL JMP
5.0 Constant for SV 7.7 7.3 2.5
5.2
:DM for SV
12.2 12.1 2.5
16 WSFT
8.1 With 1-word shift register
0.9
11.1 With 10-word shift register
532.5
With 1,024-word shift register using :DM
3,084.7
With 6,144-word shift register using :DM
20 CMP
4.6 When comparing a constant to a word
0.9
4.8 When comparing two words
14.0
When comparing two :DM
21 MOV
4.3 When transferring a constant to a word
0.9
4.8 When moving from one word to another
14.2
When transferring :DM to :DM
22 MVN
4.4 When transferring a constant to a word
0.9
4.9 When moving from one word to another
14.2
When transferring :DM to :DM
23 BIN
9.6 When converting a word to a word
0.9
19.1
When converting :DM to :DM
24 BCD
10.0 When converting a word to a word
0.9
18.9
When converting :DM to :DM
25 ASL
4.8 When shifting a word
0.9
9.5
When shifting :DM
26 ASR
4.7 When shifting a word
0.9
9.3
When shifting :DM
27 ROL
4.1 When rotating a word
0.9
8.8
When rotating :DM
28 ROR
4.1 When rotating a word
0.9
8.8
When rotating :DM
29 COM
5.2 When inverting a word
0.9
9.8
When inverting :DM
30 ADD
9.4 Constant + word → word
0.9
9.9 Word + word → word
23.6
:DM + :DM → :DM
31 SUB
9.3 Constant – word → word
0.9
10.6 Word – word → word
24.3
:DM – :DM → :DM
32 MUL
15.7 Constant word → word
0.9
16.3 Word word → word
30.9
:DM :DM → :DM
33 DIV
15.2 Word ÷ constant → word
0.9
16.7 word ÷ word → word
30.1
:DM ÷ :DM → :DM
34 ANDW
8.2 Constant Ɠ word → word
0.9
9.2 Word Ɠ word → word
22.7
:DM Ɠ :DM → :DM
35 ORW
8.1 Constant V word → word
0.9
9.0 Word V word → word
22.7
:DM V :DM → :DM
