8-3SectionCycle Time
117
Code OFF execution time (µs)Conditions (Top: min.; bottom: max.)ON
execution
time (µs)
Mnemonic
36 XORW
8.1 Constant V word → word
0.9
9.0 Word V word → word
22.7
:DM V :DM → :DM
37 XNRW
8.2 Constant V word → word
0.9
9.1 Word V word → word
23.0
:DM V :DM → :DM
38 INC
5.2 When incrementing a word
0.9
9.8
When incrementing :DM
39 DEC
5.2 When decrementing a word
0.9
9.8
When decrementing :DM
40 STC 1.2 --- 0.9
41 CLC 1.2 --- 0.9
50 ADB
9.3 Constant + word → word
0.9
10.2 Word + word → word
24.2
:DM + :DM → :DM
51 SBB
9.6 Constant – word → word
0.9
10.4 Word – word → word
24.1
:DM – :DM → :DM
52 MLB
10.5 Constant  word → word
0.9
11.4 Word  word → word
25.8
:DM  :DM → :DM
53 DVB
11.1 Word ÷ constant → word
0.9
12.0 Word ÷ word → word
26.5
:DM ÷ :DM → :DM
54 ADDL
16.1 Word + word → word
0.9
31.2
:DM + :DM → :DM
55 SUBL
16.0 Word – word → word
0.9
31.3
:DM – :DM → :DM
56 MULL
45.3 Word  word → word
0.9
61.5
:DM  :DM → :DM
57 DIVL
43.5 Word ÷ word → word
0.9
58.3
:DM ÷ :DM → :DM
58 BINL
15.1 Word → word
0.9
25.9
:DM → :DM
59 BCDL
13.5 Word → word
0.9
24.3
:DM → :DM
70 XFER
12.6 When transferring a constant to a word
0.9
13.5 When transferring a word to a word
650.5
When transferring 1,024 words using :DM
3.76 ms
When transferring 6,144 words using :DM
946.5
When transferring 2,048 words using :EM
32.9 When transferring 1 word from flash memory
using :DM
71 BSET
8.1 When setting a constant to 1 word
0.9
11.1 When setting word constant to 1 word
396.5
When setting :DM to 1,024 words
2.26 ms
When setting :DM to 6,144 words
82.5
When setting :EM to 2,048 words
