Code OFF execution time (µs)Conditions (Top: min.; bottom: max.)ON
execution
time (µs)
Mnemonic
73 XCHG
8.7 Word → word
0.9
18.1
:DM → :DM
74 SLD
7.2 Shifting 1 word
0.9
13.6 Shifting 10 word
890.5
Shifting 1,024 words using :DM
5.18 ms
Shifting 6,144 words using :DM
75 SRD
7.5 Shifting 1 word
0.9
13.3 Shifting 10 word
886.5
Shifting 1,024 words using :DM
5.18 ms
Shifting 6,144 words using :DM
80 DIST
11.7 When setting a constant to a word + a word
0.9
12.7 When setting a word to a word + a word
28.9
When setting :DM to :DM +:DM
15.9 When setting a constant to a stack
16.7 When setting a constant to a stack
81 COLL
11.8 When setting a constant + a word to a word
0.9
12.6 When setting a word + a word to a word
27.0
When setting :DM + :DM to :DM
11.0 When setting a word + constant to FIFO stack
11.8 When setting a word + word to FIFO stack
29.7
When setting a :DM + :DM to FIFO stack via
:DM
11.0 When setting a word + constant to LIFO stack
11.7 When setting a word + word to LIFO stack
28.9
When setting a :DM + :DM to LIFO stack via
:DM
82 MOVB
9.5 When moving constant to word
0.9
11.4 When moving word to word
25.5
When moving :DM to :DM
83 MOVD
8.2 When moving constant to word
0.9
10.4 When moving word to word
24.7
When moving :DM to :DM
84 SFTR
10.5 Shifting 1 word
0.9
10.8 Shifting 10 words
537.0
Shifting 1,024 words using :DM
3,049.0
Shifting 6,144 words using :DM
85 TCMP
16.1 Comparing constant to word-set table
0.9
17.7 Comparing word to word-set table
32.5
Comparing :DM to :DM-set table
91 SBS 5.8 --- 1.4
92 SBN --- --- ---
93 RET 3.7 --- 1.1
97 IORF
7.7 Refreshing one input word
1.1
6.2 Refreshing one output word
7.7 Refreshing I/O words
99 MCRO
21.3 With word-set I/O operands
0.9
33.7
With :DM-set I/O operands
10.9 Executing interrupt in CPU Unit
