5-1SectionUnit Setup Area
57
5-1-2 Details of Overall Unit Settings
Settings Enabled at Startup
Address Bits Function Contents
DM 6600
00 to 03 Disable writing to user memory (UM protect) 0 Hex: Writing enabled
1 Hex: Writing disabled
Note: Set these bits to 1 (Hex) to
prohibit writing to the following
areas from the Programming
Device: User program, read-only
portion of the DM Area, Unit Setup
Area (except for bits 00 to 03 in
DM 6600), and expansion function
data.
04 to 07 Switch between English and Japanese for Programming
Console messages
0 Hex: English
1 Hex: Japanese
08 to 11 Enable user settings for expansion instructions 0 Hex: Default settings
1 Hex: User settings
12 to 15 Holding EM Area 0 Hex: Clear
1 Hex: Held
DM 6601
00 to 07
General-purpose
I/O between the
Input refresh (for
inputs from the
C
No. of refresh
words
00 (BCD): Not refreshed
01 to 32 (BCD): 1 to 32 words
08 to 15
/O be ee e
LR Area and
user-set words in
the CPU Unit
so e
CPU Unit to the
Customizable
Counter Unit)
CPU Unit area 00 (BCD): CIO
01 (BCD): WR
02 (BCD): AR
03 (BCD): HR
04 (BCD): DM
05 (BCD): EM
DM 6602
00 to 07
Output refresh
(for outputs from
C
No. of refresh
words
00 (BCD): Not refreshed
01 to 32 (BCD): 1 to 32 words
08 to 15
(o o s o
the Customizable
Counter Unit to
the CPU Unit)
CPU Unit area 00 (BCD): CIO
01 (BCD): WR
02 (BCD): AR
03 (BCD): HR
04 (BCD): DM
05 (BCD): EM
DM 6603 00 to 15 Input refresh First word in CPU
Unit area
0000 to 9999 (BCD): 0 to 9999
DM 6604 00 to 15 Output refresh First word in CPU
Unit area
0000 to 9999 (BCD): 0 to 9999
DM 6605
to
DM 6614
00 to 15 Special I/O Setup Area ---
