Page #78 background image
5-1SectionUnit Setup Area
58
Settings Enabled at Startup and when Operation Starts
Address Bits Function Contents
DM 6615 00 to 15 Enable high-speed execution Setting other than 5A5A Hex: Normal Execution Mode
5A5A: High-speed Execution Mode
DM 6616 00 to 15 (Reserved by system.) ---
DM 6617 00 to 15 Peripheral port servicing time 0000 (BCD): Default (0.2 ms)
0001 to 0500 (BCD): Sets peripheral port servicing time in the
range 0.1 to 50.0 ms (0.1-ms units).
DM 6618 00 to 15 Cycle monitor time 0000 (BCD): Default (50 ms)
0001 to 0100 (BCD): Sets cycle monitor time in the range 1 to
100 ms (in 1-ms units).
Note: If the cycle monitor time is exceeded, a system error
(fatal error; error code: 9F), is generated.
DM 6619 00 to 15 Constant cycle time 0000 (BCD): Variable cycle time
0001 to 0500 (BCD): Sets a constant cycle time in the range
0.1 to 50.0 ms (in 1-ms units). (Even if all the necessary
processing is completed in less than the set time, the next
cycle will not start until the constant cycle time setting has
elapsed.)
Note: If the constant cycle time setting is exceeded, SR
24905 turns ON.
DM 6620
00 to 03 Interrupt input 0 (IR 00000)
function
0 Hex: Normal input
1 Hex: Interrupt input for ON
fO
Note: Settings 1 to 3 Hex are
valid in both Interrupt Input
C
04 to 07 Interrupt input 1 (IR 00001)
function
ee oO
2 Hex: Interrupt input for OFF
3 Hex: Interrupt input for ON
nd OFF
dbo e
Mode and Counter Mode.
08 to 11 Interrupt input 2 (IR 00002)
function
and OFF
12 to 15 Interrupt input 3 (IR 00003)
function
DM 6621
to
DM 6629
00 to 15 (Reserved by system.) ---
DM 6630
to
DM 6639
00 to 15 Special I/O Setup Area ---
DM 6640
to
DM 6644
00 to 15 (Reserved by system.) ---
