5-1SectionUnit Setup Area
62
Settings for Analog Outputs (CS1W-HCA22 Only)
Settings Enabled at Startup
Address Bits Function Details
DM 6613
00 to 07
Analog output 1
Output signal range 00 Hex: –10 to 10 V
01 Hex: 0 to 10 V
02 Hex: 1 to 5 V
03 Hex: 0 to 5 V
5A Hex: Output disabled (See note.)
Note: Setting 5A can be used to
shorten the I/O refresh time.
08 to 15 Operation when output turned OFF 00 Hex: Cleared
01 Hex: Held
02 Hex: Peak value
DM 6614
00 to 07
Analog output 2
Output signal range
Same as for analog output 1.
08 to 15
Operation when output turned OFF
Settings Enabled at Startup and when Operation Starts
Address Bits Function Details
DM 6630
00 to 07 For both analog
outputs 1 and 2
Analog output
method
00 Hex: END refresh (The values stored in AR 14
and AR 15 are output as analog signals after
execution of the END instruction.)
01 Hex: Immediate refresh using instructions
(Analog signal output with execution of SPED or
ACC instruction. Output values are stored in AR 14
and AR 15 for monitoring.)
08 to 15 (Reserved by
system.)
---
DM 6631 00 to 15 For both analog
outputs 1 and 2
Adjustment mode
password
5A5A Hex: Adjustment mode enabled
Setting other than 5A5A: Adjustment mode
disabled
DM 6632
to
DM 6643
00 to 15 (Reserved by
system.)
---
