6-1-2 Hold/Clear for I/O Memory Data
The following table shows when the status of the memory areas is held and
when it is cleared.
Name Addresses External I/O
Operating
Fatal errors
Power
allocation mode
changed
(See note 1.)
FALS error Other fatal
errors
supply
turned ON
Input Area IR 000 Yes Cleared Held Cleared Cleared
Output Area IR 001 Yes Cleared Cleared Cleared Cleared
Work Area IR 002 to
IR 049,
IR 200 to
IR 219
No Cleared Held Cleared Cleared
SR Area SR 220 to
SR 255
No (Refer to the individual explanations for the functions.)
AR Area AR 00 to
AR 27
No Held or cleared depending on the address.
LR Area LR 00 to
LR 31
No Cleared Held Cleared Cleared
Timer Completion
Flags
TIM/CNT 000
to TIM/CNT
255
No Held
(See note 1.)
Held Held Cleared
Timer PVs TIM/CNT 000
to TIM/CNT
255
No Held
(See note 2.)
Held Held Cleared
Counter Completion
Flags
TIM/CNT 000
to TIM/CNT
255
No Held Held Held Cleared
Counter PVs TIM/CNT 000
to TIM/CNT
255
No Held Held Held Held
DM Area
General-
purpose
read/write
words
DM 0000 to
DM 6143
No Held Held Held Held
General-
purpose
read-only
words
DM 6200 to
DM 6599
Error Log
Area
DM 6144 to
DM 6199
Unit Setup
Area
DM 6600 to
DM 6655
EM Area EM 0000 to
EM 2047
No According to
setting.
(See note 3.)
According to
setting.
(See note 3.)
According to
setting.
(See note 3.)
According to
setting.
(See note 3.)
Note 1. “Operating mode changed” means between RUN or MONITOR mode and
PROGRAM mode.
2. The status of Timer Completion Flags and Timer PVs is held when the oper-
ating mode changes from RUN mode or MONITOR mode to PROGRAM
mode, but it is cleared when the operating mode is changed from PRO-
GRAM mode to RUN mode or MONITOR mode.
3. It is possible to set whether data in the EM Area is held or cleared in the Unit
Setup Area (bits 12 to 15 in DM 6600).
4. With the Customizable Counter Unit, there is no function (e.g., such as an
IOM Hold Bit) for holding the bit status in the cleared areas above when the
operating mode is changed or the power supply is turned ON.
