Assembly Memory Allocation
Member Name Data Type Bit Number Data Length Byte Offset
32 bit User Defined Tag Echo DINT 4 Byte 0
UserTag_1 0 1 bit
UserTag_2 1 1 bit
UserTag_3 2 1 bit
UserTag_4 3 1 bit
UserTag_5 4 1 bit
UserTag_6 5 1 bit
UserTag_7 6 1 bit
UserTag_8 7 1 bit
UserTag_9 8 1 bit
UserTag_10 9 1 bit
UserTag_11 10 1 bit
UserTag_12 11 1 bit
UserTag_13 12 1 bit
UserTag_14 13 1 bit
UserTag_15 14 1 bit
UserTag_16 15 1 bit
UserTag_17 16 1 bit
UserTag_18 17 1 bit
UserTag_19 18 1 bit
UserTag_20 19 1 bit
UserTag_21 20 1 bit
UserTag_22 21 1 bit
UserTag_23 22 1 bit
UserTag_24 23 1 bit
UserTag_25 24 1 bit
UserTag_26 25 1 bit
UserTag_27 26 1 bit
UserTag_28 27 1 bit
UserTag_29 28 1 bit
UserTag_30 29 1 bit
UserTag_31 30 1 bit
UserTag_32 31 1 bit
32 bit Command Echo DINT 4 Byte 4
Trigger_Echo 0 1 bit
New Master Echo 1 1 bit
Reserved 2 - 7 6 bit
Disable Scanning Echo 8 1 bit
Reserved 9 - 15 7 bit
Clear Read Cycle Report and
Counters Echo
16 1 bit
Unlatch Outputs Echo 17 1 bit
Reserved 18 - 31 14 bit
