3-2-4
Setting the Data to Output after a Read
The code reader can be configured so that after a Read is executed, its read results are automatically
output to the TCP port it is connected to. Additional information such as print quality grade and code
position coordinates can be appended to the Read result output and the format of that output can be
modified.
Change the Read Result Output Condition
You can change the conditions by which you will output your Read results.
• WebLink - Setup - Gear Icon -
Advanced Settings - I/O - Symbol Data Output
Setting Item Setting Value Description
Symbol Data Output
• Disabled
• Match
• Mismatch
• Good Read
(default)
• Only If All Are
Good Reads
• Disabled: Read result is not output.
• Match: The Read result is only output when it matches the
Master Symbol set in the Matchcode function.
• Mismatch: The Read result is only output when it does not
match the Master Symbol set in the Matchcode function.
• On Good Read: Read results are output for even just one Good
Read.
• Only If All Are Good Reads: The Read result is output only
when all the symbols specified in the Read Multiple Symbols
function are successfully read.
Output Timing
• As Soon As Pos-
sible
(Default)
• End of Read Cy-
cle
• As Soon As Possible: Outputs the Read result immediately on
Good Read and ends the Read Cycle.
• End of Read Cycle: The Read result is not output until the End
of Read Cycle condition is met. The End of Read Cycle condi-
tion is set in Advanced Settings - Read Cycle - End of Read
Cycle.
Set the data to be output when there is a No Read.
You can change the data to output when there is a No Read result.
• WebLink - Setup - Gear Icon - Advanced Settings - I/O - No Read Message
Setting Item Setting Value Description
No Read Message
• Enabled
(default)
• Disabled
• Enabled:
A message is output when there is a No Read. However, if
the Trigger Mode set in Read Cycle is Continuous Read, no
message is output regardless of this setting.
• Disabled:
No message is output for a No Read.
Message NOREAD
(default)
Set the message to output when there is a No Read. You can
set up to 64 ASCII characters.
Header and Footer Settings
You can change the Header (Preamble) and Footer (Postamble) that precedes and follows the Read
string.
3 Controlling Operation and Data Output with Ethernet
3 - 32
V430-F Series Autofocus Multicode Reader User Manual for Communication Settings
